Gentry - aperture (Aperture) :
76 cm
Gentry - a digital tilt:
±50°
Gentry - rotational speed :
0,286 с
X-ray tube - heat capacity:
7.5 MHU
X-ray tube - heat dissipation:
1386 kHU/min
X-ray tube - size of the focal spot:
1.2-1.4 mm
X-ray tube - type of cooling:
Oil + Air
Generator - power :
80 kW
Generator - voltage (kV):
70, 80, 100, 120, 140
Generator - current (mA):
10-800 mA
Generator - maximum scan duration :
100 с
Detector - rows:
64 (128 slices)
Detector - slice thickness:
0.625 mm
Detector - detector coating:
40 mm
Detector - width of the spiral collection:
0.3125-5 mm
Detector - channels in a line:
912
Detector - number of detectors:
58 368
Detector - type of detector:
Solid state
Workstation - capacity :
HDD 2TB + 2×512GB
Workstation - archiving:
CD/DVD/USB
Workstation - monitor:
24" LCD
Workstation - resolution:
1920×1200
Patient table - vertical range :
490-990 mm
Patient's table - longitudinal view:
1850 mm
Patient table - scanning range:
1800 mm
Patient table - max. load capacity :
230 kg
Reconstruction - Pitch:
0,1-2,0
Reconstruction - the speed of reconstruction:
100 frames per second
Reconstruction - reconstruction matrix :
1024×1024
Reconstruction - mapping matrix (optional):
1024×1024
Dose control - techniques :
A-dose, Pediatric protocols, D-dose
Dose control - iterative reconstruction:
Admir3D
Image quality - high contrast:
21 lp/cm @0% MTF
Image quality - low contrast:
2.0 mm @0.30%
Image quality - CT number range:
-32 767 ~ 32 768
3D reconstruction:
3D, MIP, MinIP, SSD, MPR, VR
